Customized Horizontal Pulse Filter Cartridge Dust Collector Big Airflow

Working Principle of Cartridge Filter Dust Collector

1. Dusty gas enters the collector through the air inlet and first flows through an air distribution device. This part spreads the gas evenly before sending it to the filter cartridge zone.

2. The filter cartridges, often flame-retardant, are made of premium materials such as glass fiber and polyester fiber, and have a dense microporous structure. As polluted air passes through, dust particles get trapped on the cartridge surface. This occurs either because the particles are bigger than the filter pores, or due to collision, interception and diffusion with the fibers. Even ultrafine dust can be captured, since Brownian motion increases its contact with the fibers.

3. As dust accumulates, filtration resistance goes up. This triggers the pulse-jet cleaning system. Compressed air is released instantly through pulse valves, and venturi tubes suck in a large amount of surrounding air to rush into the cartridges. The strong airflow makes the cartridges expand and flex quickly, shaking off the dust layer. The removed dust then falls into the ash hopper at the bottom for disposal.

Product video: Filter cartridge dust removal equipment collector.mp4

Horizontal cartridge filter dust collector system include whole set equipment, apply the pulse jet dust cleaning way, PLC control system to operate, collect and clean all industrial dust powder efficiently.

Construction of cartridge dust removal equipment:

1) Material: Carbon steel or stainless steel
2) Installed with pulse valves and control system
3) Block building structure, can be constructed to handle the required airflow

Features of cartridge filter dust removal equipment:

1. Equipped with high efficiency and advanced flame retardant cartridge.

2. Automatic Pulse jet cleaning method for the filter makes machine to work continuously.

3. Large volume of dust drawer ad easy to remove and deal with dust.

4. According to different size and application change the filter cartridge.

5. Real-time monitoring of machine pressure changes can quickly detect whether the filter clean or not

6. Explosion proof motor and electrical control cabinet guarantees the safe running of the machine

Filter Cartridge Dust Collector popular suitable for wood working, grinding, cutting, feeding and other applications with a large amount of dust in the centralized.
